Sapphire Nitro+ Radeon RX 580, 4GB GDDR5

Sapphire Nitro+ Radeon RX 580, 4GB GDDR5


Sapphire
48h Usually ships within 48hrs.

US$282.99

add to cart orsave for later


Manufacturer
Sapphire
48h Usually ships within 48hrs
Price
US$282.99
Click on a thumbnail to see more pictures for Sapphire Nitro+ Radeon RX 580, 4GB GDDR5
Sapphire Nitro+ Radeon RX 580, 4GB GDDR5Sapphire Nitro+ Radeon RX 580, 4GB GDDR5Sapphire Nitro+ Radeon RX 580, 4GB GDDR5Sapphire Nitro+ Radeon RX 580, 4GB GDDR5Sapphire Nitro+ Radeon RX 580, 4GB GDDR5

features

  • DirectX: 12.0
  • OpenGL: 4.5
  • OpenCL: 2.0
  • Shader Model: 5.0

Specs

RAM bandwidth
4GB GDDR5, 1750MHz, 256bit, 224GB/s
Performance
6502GFLOPS (Single), 406GFLOPS (Double)
Coreclock
1257MHz, Boost: 1411MHz
Shader-Units/TMUs/ROPs
2304/144/32
Cooling
2x Axial-fan (95mm, detachable)
Graphics Card Interface
PCIe 3.0
Design Height
Dual-Slot
Codename
Polaris 20 XTX
Connectivity
DisplayPort 1.4
DVI
HDMI 2.0
Dedicated GPU
Radeon RX 580
Graphics Card
AMD Radeon
Lithography (nm)
14 nm
Power consumption
185W (TDP)
Power interface
1x 8-pin PCIe + 1x 6-pin PCIe
RAM
4GB

description

AWARD-WINNING DESIGN, TOP PERFORMANCE

​Built on the future-proof Polaris architecture, the SAPPHIRE NITRO+ Radeon™ RX 580 graphics card plays your favorites at a smooth 1080p and beyond, from the latest eSports games and MOBAs to the most popular, graphically-intensive AAA titles. The evolution of the FinFET 14 process has allowed the new RX 500 Series to achieve higher clocks versus previous generations.

System Requirement

500 Watt Power Supply (Suggestion)
1 x 8-pin + 1 x 6-pin (optional) AUX Power Connector
CD-ROM or DVD-ROM drive for installing software

further info

Official Release Date Apr 18, 2017
PAX-Code PAX0008971954
Catalog No.  11265-07-41G
Item Code  4895106282469
Product Measures 37cm x 25cm x 7cm

recommendations

useful links


Missing links?

Please log in or create account to submit your link recommendations.

customer reviews

Average rating:  Too few reviews (min 3 reviews required)
Total votes:2

If you are familiar with Sapphire Nitro+ Radeon RX 580, 4GB GDDR5, why not let others know?

Please note that opinions expressed in any review are those of our customers and do not necessarily match those of the Play-Asia.com team.

ths.saisoks (1) on 22, Jul. 2017 23:07 (HKT)
Good gpu
Quality products And very fast delivery
[Do you think this review was helpful? ]
imikeskinner (1) on 28, Apr. 2017 17:13 (HKT)
Amazing for the size and power consumption.
I bought this for an old Dell machine which only had enough space for a motherboard-powered, single-slot, low-profile graphics card. I'd hoped to use it as a media center, but it also runs new games at mid-spec and everything from maybe 2013 backwards at top. This is with ageing DDR2 DIMMs and an old processor provisioned to reliably run Excel 2010 on someone's desk. This is also the 2GB GDDR5 edition, which I couldn't find anywhere else. It seems to compensate for the 64-bit memory bus to some extent. What it does with the power it draws down is most impressive, the stock Dell PSU I'm using it with has very little wattage to spare but it's still happily playing X-COM 2 at medium spec.
